Pro 12 Sub

  • Sale
  • Regular price $3,541.45
bread


The Pro 12 Subwoofer from Legacy Audio is the ideal subwoofer solution for low frequency extension in the studio or small theater.

Pro 12 takes advantage of the piston area that only a 15" down-firing radiator can provide. Use it in your home theater system to enhance low frequency effects or go way down deep to discover the hidden bass lines in your music. This kind of extension can only be achieved in a compact enclosure by supplying serious power - 750 real watts to be precise - to an efficient long throw 12" subwoofer. This driver offers the highest Xmax available in its efficiency class, a 3" dual 4 layer voice coil and a 480oz motor structure.

The Pro 12 subwoofer offers the performance of the home line Metro XD subwoofer, in a simplified cabinet design. As with the Metro XD, the back panel features four controls: Level, Freq., Blend and Phase. These allow an extraordinary amount of control over your subwoofer. These controls will allow you to tailor the sound of the sub to your room and integrate with your main speakers.

Specifications:

  • Application: Studio or smaller theater sub
  • System Type: Subwoofer, pneumatically coupled long-throw
  • Mounting: Floor
  • System Directivity: Omni
  • Cubic space per subwoofer: up to 4000 cubic ft room
  • Subwoofer: 12" spun aluminum diaphragm, 480oz motor structure, cast frame, 3" dual 4 layer voice coil
  • Sub-Bass Radiator: 15" mass loaded down firing
  • Frequency Alignment: 6th Order
  • Freq. Response (Hz, +/-2dB): 20-150
  • Impedance: 10k Ohm amp input
  • Phase Adjustment: Cont. +/- 180
  • Blend EQ: (+/- 12dB@45Hz)
  • Sensitivity (Room, dB@ 2.83V): 1.0 volts to rated output
  • Crossover Freq. (Hz): 40-150
  • Inputs: LFE, L/R RCA, balanced XLR
  • Internal Amplification: 750 Watts, Class D ICEpower®
  • Low Pass Filter Slope:1 8 dB per octave
  • Max SPL: 118 dB @ 1m
  • Idle Noise: 90 microvolts
  • Protection Schemes: thermal reset
  • Dimensions (HxWxD, inches): 18 x 16 x 16
  • Weight: 70 lbs
