NAD C 568 Compact Disc Player


Please call us at 416.821.4723 for pricing & availability or

Overview

The C 568 takes the superb performance of our 5-star rated C 565BEE and steps it up to the next level. Every aspect of sonic performance is enhanced and refined, making the C 568 the ideal companion to our C 368 amplifier, or any system in need of a performance upgrade.

Besides the new, more refined cosmetics, the circuit layout and component choices of the C 568 have been extensively updated since the C 565BEE’s reign. The cumulative effect of these changes is dramatic, improving low frequency slam and extension, while maintaining the pace and timing for which the C 565BEE was so lavishly praised. Image depth and scale are further enhanced while retaining the timbral accuracy and lucid harmonic structure of its predecessor.

Features

  • CD, CD-R and CD-RW Compatible
  • USB Input supports external memory and audio rates up to 384kbps
  • MP3 and WMA decoding
  • NAD CD-8 full function remote control
  • Ultra-High Precision Clock Module for lowest jitter
  • Wolfson 24 bit Digital to Analogue Converter
  • Super High-Speed OPAmps
  • Coaxial Digital Output
  • Optical Digital Output
  • Toroid Power supply with separate power regulators for analogue and digital sections
  • VFL Display with CD text
  • Selectable Track, Time and Repeat
  • Repeat Mode for single track or entire CD
  • Program Play up to 20 tracks
  • Random Play
  • External IR input
  • 12V Trigger input
  • <0.5 watt Standby consumption
  • Detachable AC cord

Specifications

Output level

Analog: 2.2 ± 0.1 V

Optical: -22.5 ±3.5dBm

Coaxial: 650 ±150mV

Frequency response

±0.3 dB (ref. 0 dB 20 Hz-1 kHz)

±0.5 dB (ref. 0 dB 5 kHz-20 kHz)

Total harmonic distortion
≤0.01% (ref. 1 kHz, Audio LPF)
Signal/Noise ratio
118 dB (ref. 1 kHz, A-weighted LPF Stop, Pause)
Channel balance
±0.5 dB (ref. 0dB 1kHz)
Dynamic range 95dB
Channel separation
>90dB
De-emphasis

-3.73 to -5.33 dB (ref. 0dB 1 kHz, 5 kHz)

-8.04 to -10.04 dB (ref. 0dB 1 kHz, 16 kHz)

Linearity

±0.01 dB (ref. 0dB 1 kHz at -3 dB)

±0.02 dB (ref. 0dB 1 kHz at -6 dB)

±0.02 dB (ref. 0dB 1 kHz at -10 dB)

±0.05 dB (ref. 0dB 1 kHz at -20 dB)

±0.15 dB (ref. 0dB 1 kHz at -60 dB)

USB Output level 2.2 ±0.2V
USB Frequency Response ±1dB (ref. 0dB 20Hz – 16kHz)
USB Total Harmonic Distortion <0.03% (ref. 0dB 1kHz, Audio LPF)
USB Signal/Noise Ratio 118dB (ref. 1kHz, A-weighted Pause)
Standby power
<0.5W
Gross dimensions (W x H x D)

435 x 80 x 306mm

17 1/8 x 3 3/16 x 12 11/16″

Net Weight 4.9kg (10.8lb)
Shipping Weight 6.9kg (15.2lb)
