M17 V2 Surround Sound Preamp Processor - Summit Hi-Fi
M17 V2 Surround Sound Preamp Processor - Summit Hi-Fi M17 V2 Surround Sound Preamp Processor - Summit Hi-Fi
$0.00

The M17 V2 offers full HDMI video switching and surround sound decoding along with 11.1 balanced outputs. Brimming with a full complement of sophisticated features like the high resolution lossless surround formats from Dolby TrueHD and DTS-HD Masters Audio decoding, and now object-based audio with Dolby Atmos, the M17 provides the highest levels of performance. The surround mode of the source material is automatically detected via the digital inputs of the M17V2, and the most advanced form of decoding, based on your setup, is switched in. Conversion of the encoded digital bitstream is performed with high resolution and extremely linear D/A converters carefully selected for their performance capabilities.

LINE INPUT/PRE OUT

HDMI        Up to 4K UHD

Coaxial    0.5 Vpp

Ethernet  RJ45 10/100/1000 Ethernet

 LINE LEVEL INPUT

Input Impedance (R and C)    56kΩ + 220pF

Input Sensitivity            40mV (ref. 500mV out)

Maximum Input Signal >8Vrms

Signal/Noise Ratio, A-weighted        >90dB (ref. 500mV in, 500mV out, volume                                                                    set to unity gain)

                                                              >80dB (ref. 2V out, volume maximum)

Channel Separation                 >70dB (ref. 1kHz / 10kHz)

Frequency Response             ±0.3dB (ref. 20Hz – 20kHz, Tone Active)

                                                  ±0.3dB (ref. 20Hz – 20kHz, Tone Defeat)

Frequency Response (subwoofer out)       10 – 200Hz (ref. -3dB)

 OUTPUT

XLR          >2Vrms

Maximum output level >8Vrms into 600Ω

THD (CCIF IMD, DIM 100)       <0.005% (ref. 20Hz – 20kHz, 2V out)

Tone Controls   Treble | ±10dB at 10kHz (ref. 2V in, 2V out)

                           Bass | ±10dB at 100kHz (ref. 2V in, 2V out)

 GENERAL

Standby power              <0.5W

Unit Dimension (WxHxD) – Gross*             435 x 156 x 386mm

                                                                       17 1/8 x 6 3/16 x 15 1/4 inches**

Net Weight                     10.9kg (24lb)

Shipping Weight            17.5kg (38.6lb)
