Featuring state of the art ICEedge® technology, the elegant i·V3 Ultra amplifier approaches 80% efficiency while delivering over 600 watts per channel into 8 ohms, both channels driven. Such exceptional power is the product of very high current (i) and voltage (V) output capabilities providing stability into low impedances with a peak output current capability of 38A.
Specifications:
- Product ManualDownload Manual
- Power Rating:1000 watts per channel x 3 @ 4 ohms, all channels driven 610 watts per channel x 3 @ 8 ohms, all channels driven
- Peak Power:1.2 kW peak power from any channel @ 4 Ohm/1kHz with less than 1% distortion
- Over Current Protection:Breaker reset for excessive sustained current
- Inputs:Fully balanced XLR, single-end RCA
- Outputs:Gold plated safety approved five-way binding posts
- Damping factor:750 average, 20Hz to 1kHz
- Voltage Gain:25.8 dB
- Dynamic Range:127dB, A- weighted
- Voltage/Current:98 Vp / 38Ap
- Input Sensitivity:5.0Vp @ 1200W/4 Ohm
- Input Impedance:38 kOhm for both pin 2+ and pin 3-
- Channel Separation:120 dB at 1kHz
- Unit Dimensions:17.5″ W x 15.6″ D x 5.8″ H
- Unit Shipping Weight:30 lbs each
- Notes:Highest power output can be obtained using a single 230V, 20A line or dual 120V, 20A lines. A conventional single AC cord is provided.
