i-V3 Ultra

  • Sale
  • Regular price $10,398.30


Featuring state of the art ICEedge® technology, the elegant i·V3 Ultra amplifier approaches 80% efficiency while delivering over 600 watts per channel into 8 ohms, both channels driven. Such exceptional power is the product of very high current (i) and voltage (V) output capabilities providing stability into low impedances with a peak output current capability of 38A.

Specifications:

  • Product ManualDownload Manual
  • Power Rating:1000 watts per channel x 3 @ 4 ohms, all channels driven 610 watts per channel x 3 @ 8 ohms, all channels driven
  • Peak Power:1.2 kW peak power from any channel @ 4 Ohm/1kHz with less than 1% distortion
  • Over Current Protection:Breaker reset for excessive sustained current
  • Inputs:Fully balanced XLR, single-end RCA
  • Outputs:Gold plated safety approved five-way binding posts
  • Damping factor:750 average, 20Hz to 1kHz
  • Voltage Gain:25.8 dB
  • Dynamic Range:127dB, A- weighted
  • Voltage/Current:98 Vp / 38Ap
  • Input Sensitivity:5.0Vp @ 1200W/4 Ohm
  • Input Impedance:38 kOhm for both pin 2+ and pin 3-
  • Channel Separation:120 dB at 1kHz
  • Unit Dimensions:17.5″ W x 15.6″ D x 5.8″ H
  • Unit Shipping Weight:30 lbs each
  • Notes:Highest power output can be obtained using a single 230V, 20A line or dual 120V, 20A lines. A conventional single AC cord is provided.
