D 3020 V2 Hybrid Digital DAC Amplifier - Summit Hi-Fi
D 3020 V2 Hybrid Digital DAC Amplifier - Summit Hi-Fi D 3020 V2 Hybrid Digital DAC Amplifier - Summit Hi-Fi
$499.00

The original NAD 3020 introduced a generation of music lovers to true high-fidelity sound. In the 1970’s, over a million people rediscovered their music when they placed a NAD 3020 between their turntable and loudspeakers. This little gem outshined amplifiers costing 10 times more with its big, warm, detailed sound. Today, the source is more likely to be a computer or smartphone than a turntable, but the ability to choose speakers that perfectly suit one’s taste is still a compelling argument for upgrading to an NAD amplifier. The D 3020 starts with the original NAD 3020 concept and brings it straight into the 21st century using the latest high-speed digital technology. Now with V2, we have refined the looks and added a Phono input for vinyl playback.

AUDIO SPECS

Rated Power at 8 ohms         2 x 30 Watts

IHF Dynamic Power 8 ohms  2 x 60 Watts

4 ohms                           2 x 100 Watts

2 ohms                           2 x 150 Watts

Signal/Noise Ratio (A-weighted, ref. 1 Watt)     ≥90dB

Channel Separation 1kHz      ≥75dB

10kHz                                     ≥65dB

Channel Balance                   0 ±0.3dB

Frequency Response (20Hz – 20kHz)  0dB to -0.3dB

Total Harmonic Distortion   ≤0.005%

Maximum input level            5V

IMD (SMPTE)                         0.02%

IMD (CCIF)                             0.003%

MM PHONO INPUT

Phono Signal-to-Noise Ratio    >82 dB (200 ohms source, A-weighted, ref. 500 mV out)
                                                    76 dB (MM cartridge source, IHF; A-weighted, ref. 500 mV out)

Input sensitivity             1.15 mV (ref. 500 mV out, Volume maximum)

Maximum input signal at 1kHz    >90 mVrms (ref. 0.1 % THD)

Frequency response       ±0.3 dB (20 Hz – 20 kHz)

GENERAL

Standby Power               ≤0.5 Watts

Supports bit rate/sample rate    up to 24/192 (via Digital Audio input)

Unit Dimensions (W x H x D) Gross   58 x 186 x 219mm

                                                         2 5/16 x 7 3/8 x 8 5/8”

Net Weight                   1.38kg (3.05lb)

Shipping Weight            2.1kg (4.6lb)
