C 328 Hybrid Digital DAC Amplifier - Summit Hi-Fi
C 328 Hybrid Digital DAC Amplifier - Summit Hi-Fi C 328 Hybrid Digital DAC Amplifier - Summit Hi-Fi
$699.00

For 45 years, NAD Electronics has introduced aspiring audiophiles to the vast world of hi-fi. From our flagship Masters Series, to our budget-friendly Classic Series, NAD has a component for everyone. Following in the footsteps of some of NAD’s greatest units, the NAD C 328 delivers the most fundamental of features, while firmly adhering to NAD’s unwavering commitment to exquisite sound. The C 328 can wirelessly connect to any smartphone, tablet, or Bluetooth®-enabled device within range, to give you a seamless listening experience. Featuring a MM phono input, the C 328 breathes new life into vinyl LPs, thanks in part to NAD’s innovative Hybrid Digital™ amp technology. The C 328 also features a headphone amplifier, letting you connect your favourite headphones and settle back into your own world of detailed sound. Although more modest in comparison to other Classic Series amplifiers, the C 328 will fit perfectly into your existing system and bring you the musical nirvana you’ve been searching for.

ANALOGUE IN/HEADPHONE OUT

THD (20 Hz – 20 kHz)      <0.005 % at 1 V out

Signal-to-Noise Ratio     >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)

Frequency response        ±0.3 dB (20 Hz – 20 kHz)

Output impedance          11 ohms

ANALOG IN/SUBWOOFER OUT

THD (20 Hz – 20 kHz)       <0.005 % at 1 V out

Signal-to-Noise Ratio     >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)

Frequency response        ±0.2 dB (20 Hz – 20 kHz)

Output impedance         200 ohms

ANALOG IN/SPEAKER OUT

THD (20 Hz – 20 kHz)      <0.03 % (100 mW to 40 W, 8 ohms and 4 ohms)

Signal-to-Noise Ratio     >95 dB (A-weighted, 500 mV input, ref. 1 W out 8 ohms)

Frequency response       ±0.3 dB (20 Hz – 20 kHz)

PHONO IN/SPEAKER OUT

THD (20 Hz – 20 kHz)      <0.03 % (200 mW to 40 W, 8 ohms and 4 ohms)

Signal-to-Noise Ratio     >75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)

Frequency response(RIAA deviation)  ±0.3 dB (20 Hz – 20 kHz)

Note:The RIAA response is consistent with a pre-emphasis that is rolled off at 50kHz by a second order filter, such as used in Neumann cutting lathes.

DIMENSIONS & WEIGHT

Gross dimensions (W x H x D)   435 x 70 x 285 mm (17 1/8 x 2 13/16 x 11 1/4″)

Net weight                       4.9 kg (10.8 lbs)

Shipping weight              5.9 kg (13.0 lbs)
