Overview
When it comes to an NAD product, the utmost attention to detail is paid. From the heavy gauge steel chassis to the advanced power supplies and copper buss bars, the C 275BEE represents all that NAD stands for. Equipped with NAD’s ATOLogic circuit, which includes both a 12V-trigger system and signal-sensing power-on option, this extra level of flexibility makes it easy to integrate the C 275BEE into any control system. The C 275BEE also benefits from NAD’s PowerDrive™ circuit topology, which allows the C 275BEE to deliver maximum performance under various circumstances. Delivering a well-rounded, mesmerizing performance, the C 275BEE will let you hear your music the way it was meant to be heard.
Features
- 2 x 150W Continuous Power into 4 Ohms and 8 Ohms
- 250W, 410W, 600W IHF Dynamic power into 8, 4 and 2 Ohms, respectively
- PowerDrive™ circuit
- Holmgren Toroidal Power transformer
- All discrete circuitry
- Class A Voltage Stages
- Distortion Canceling Circuit
- BEE Anti-Saturation Clamp
- Short signal path from input to output
- All Sockets Gold-plated
- Soft Clipping™
- ATOLogic 12volt trigger/ signal sensing input
- Detachable IEC Power Cable
- <1W Standby Power Consumption
- Free of lead and other environmentally dangerous substances
Specifications
| Continuous output power into 8 Ohm and 4 Ohm (both channels driven) | >150W (ref. rated THD, 20Hz – 20kHz) |
| Continuous output power into 8 Ohm (Mono, Bridge mode) | >330W (ref. 20Hz – 20kHz, (Mono, Bridge mode) <0.02% THD) |
| Rated THD (250mW to rated power, CCIF IMD, DIM 100) | <0.008% (ref. 20Hz – 20kHz) |
| Clipping power (4 Ohm and 8 Ohm) | >170W (ref. 1kHz 1% THD) |
| IHF Dynamic Power |
250W at 8 Ohm 410W at 4 Ohm 600W at 2 Ohm |
| IHF dynamic power (Bridge mode) |
800W at 8 Ohm 1200W at 4 Ohm |
| Peak output current | >50A (ref. 1 Ohm, 1ms) |
| Signal/Noise ratio |
>102dB (A-weighted, ref. 1W) >123dB (A-weighted, ref. 150W) |
| Damping factor | >180 (ref. 8 Ohm, 50Hz and 1kHz) |
| Frequency response |
±0.1dB (ref. 20Hz – 20kHz) 3Hz – 100kHz (ref. -3dB) |
| Input impedance (Fixed IN) | 10 kilohm + 200pF |
| Input impedance (Variable IN) | 100 kilohm + 100pF |
| Input Sensitivity | 1.2V (ref. rated power) |
| Voltage gain | 29dB |
| Minimum input level for AUTO TRIGGER | 10mV at 1kHz |
| Time to power OFF at no signal in AUTO mode | <10 minutes |
| Power Consumption |
Normal Operation - 312W (ref. 230V AC 50Hz; 120V AC 60Hz) Standby Power - <1W Idle Power - <100W |
| Net Dimensions (W x H x D) |
435 x 133 x 352mm 17 1/8” x 5 1/4” x 13 3/4” |
| Gross Dimensions (W x H x D) |
435 x 150 x 396mm 17 1/8” x 6” x 15 3/8” |
|
Net weight |
32.2 lbs (14.6 kg) |
|
Shipping weight |
37.3 lbs (16.9 kg) |
