Overview
A remarkably affordable stereo amplifier, the NAD C 268 has features and technology unmatched by other amplifiers in its class. Designed for multiple stereo setups, the C 268 can be used in a variety of scenarios, including traditional stacks with a preamplifier or for bi-amping your favourite loudspeakers. The NAD C 268 is even bridgeable, seamlessly transforming its bountiful output from 80 x 2 to an outstanding 300 watts. Although the C 268 may appear to be a straightforward power amplifier, this Classic Series amp is brimming with rich features that will elevate your system.
Features
- 80W x 2 Continuous Power into 8 or 4 Ohms
- Stereo Dynamic Power 120/200/250 @ 8/4/2 Ohms
- 300W x 1 Continuous Power into 8 or 4 Ohms Bridge Mode
- Mono Dynamic Power 500/540W @ 8/4 Ohms
- Balanced Line Inputs
- Single-Ended Line Inputs
- Variable Input Level Control
- Line Output for Daisy Chaining
- 12V Trigger In/Out
- Auto Turn-on with Selectable Threshold
- Ground Lug
- Detachable AC Power Cord
Specifications
| Continuous output power into 8 and 4 Ohms(Stereo mode) | 80W (ref. 20 Hz-20 kHz at rated THD, both channels driven) |
| Continuous output power into 8 Ohms (Bridge mode) | 300W (ref. 20 Hz – 20 kHz at THD 0.03%) |
| THD (20 Hz – 20 kHz) | <0.03 % (250 mW to 80 W, 8 Ohms and 4 Ohms) |
| IHF dynamic power (Stereo mode, at 1 kHz 1 % THD) |
120W at 8 ohms 200W at 4 Ohms 250W at 2 Ohms |
| Damping Factor | >100 (ref. 8 ohms 20 Hz – 20 kHz) |
| Input Sensitivity (for 80 W in 8 Ohms) | 750mV/50kohms |
| Frequency Response | ±0.3 dB (20 Hz – 20 kHz) |
| Standby power | <0.5W |
| Unit Dimension (WxHxD) – Gross | 435 x 100 x 390 mm |
| Net weight | 7.3 kg (16.1 lbs) |
| Shipping weight | 8.7 kg (19.2 lbs) |
